10.1″ Integrated Customer Display (Non-Touch)
- 10.1″ TFT LCD, EDP
- 1280 RGB(H) × 800(W) Resolution
- USB Interface
- Compatible w/the SKY 15-Si and 15J
Product Details
Specifications
Overview
TEAMSable SKY 10N
- 10.1" TFT LCD, EDP
- 1280 RGB(H) × 800(W) Resolution
- USB Interface
- Compatible w/the SKY 15-Si and 15J
Configurations
Compatible with SKY 15-Si & 15-SJ
Integrated 10.1" TFT LCD Display
High-Definition Display
1280 x 800 (16:9) High-Resolution
Slim Design
Slim space saving form factor
| MODEL | DESCRIPTION |
| SKY-10N | Integrated 10" Customer Display for SKY Terminals (Non-Touch) |
Packaging
| Box Details | 9.7” (W) x 6.4” (H) x 0.9” (D) Weight: 1 kg (2.1 lbs.) |
| Inside the Box | 10.1" Customer Display |
| HARDWARE | |
| Display Method | 10.1" (16:9 Diagonal) TFT LCD, EDP |
| Resolution | 1280 RGB(H) x 800(W) |
| Interface | USB |
| Brightness | 350 Nits |
| Power Consumption | 2.5W |
| Power Supply | 5~12V, 500mA |
| ENVIRONMENT | |
| Operating Temp. | 0°C - 40°C (32° - 104°F) |
| Storage Temp. | -10°C - 55°C (14°F - 131°F) |
| Relative Humidity | 10% - 90% (Non-Condensing) |
| PACKAGE | |
| Dimension | 9.7" (W) x 6.4" (H) x 0.9" (D) inches |
| Weight | 1 kg (2.1 lbs.) |
