22″ Android System

  • 21.5″ TFT LCD
  • Cortex A17, Quad-Core 1.6GHz / Cortez A72 + A53, Six-Core 1.7GHz
  • 2GB RAM / 4GB RAM
  • 16GB eMMC
  • Android 9.0/11.0
SKU: 22P-RM-DS Category:
Product Details
Specifications
Downloads
Overview

TEAMSable 22P-RM-DS and 22P-RMX-DS


  •  21.5" TFT LCD
  • Cortex A17, Quad-Core 1.6GHz / Cortez A72 + A53, Six-Core 1.7GHz
  • 2GB RAM / 4GB RAM
  • 16GB eMMC
  • Android 9.0/11.0
Configurations
22P-RM-DS
Integrated MSR
Wall-mount bracket
Integrated Scanner
Slim Design
Wallmount Kit
MODEL DESCRIPTION
22P-RM-DS 21.5" TFT LCD Panel PC with Cortex A17 (3288), 2GB SDRAM, 16GB eMMC Flash, Android 9.0
22P-RMX-DS 21.5" TFT LCD Panel PC with Cortex A53 (3399), 4GB SDRAM, 16GB eMMC Flash, Android 9.0/11.0
PERIPHERALS DESCRIPTION
TSA-BK101 Wall mount kit 75×75 or 100×100 mm
Module-Scanner Scanner Module for Android (15N, 22P)
Android Module-MSR MSR Card Reader for Android Terminals
Packaging
BOX DETAILS INSIDE THE BOX
23.5"(L) x 15.25"(W) x 15.75"(H)
Weight: 14 lbs.
22" Android Digital Sign
Power Adapter
Wall-mount bracket ( Optional )
HARDWARE
Display 21.5" (16:9 Diagonal) TFT LCD, LVDS
Resolution 1920 RGB(H) x 1080(V)
Touch Technology 10 Point Capacitive
CPU

Cortex A17, Quad-Core, 1.6GHz

Cortez A72 + A53, Six-Core 1.7GHz

Memory 2GB DDR3 / 4GB DDR3
Storage 16GB eMMC
Power Supply 12V/5A Adapter
Wireless Wi-Fi: IEEE 802.11a/b/g/n, Bluetooth 4.0
Ethernet RJ45: 10/100/1000 Mbps LAN, POE (Optional)
MEDIA SUPPORT
Format Video: MKV, TS, FLV, AVI, VOB, MPG, DAT, ASF, RM, MOV, 3GP, MP4, WMV
Audio: MP2, WMA, WAV, AAC, OGG, ASF
Picture: JPG, BMP, GIF
OS SUPPORT
Android Android 9.0, Android 11.0 (RMX Only)
EXTERNAL PORTS
USB USB 2.0 Type-A x 4
USB Micro USB 2.0 x 1
HDMI Mini HDMI x1
SD Card Slot SD Card (SDHC Class10 compatible) x 1
GPIO Port GPIO x 2
Ethernet RJ45 with 5V/12V x 2
DC Adapter Slot 12V/5A x 1
Audio 3.5mm Jack x 1, S/PDIF x 1
Speaker Stereo Speaker: 5W x 2, Amplifier: 1.25W x 2
Mount VESA 100x100mm
ENVIRONMENT
Operating Temp. 0°C - 40°C (32° - 104°F)
Storage Temp. -10°C - 55°C (14°F - 131°F)
Relative Humidity 10% - 90% (Non-Condensing)
PACKAGE
Dimension 23.5"(L) x 15.25"(W) x 15.75"(H)
Weight 14 lbs.

A Smaller Digital Display for Smaller Spaces

Digital displays have skyrocketed in popularity in the past few years. But as digital displays have gotten bigger and better, they’ve also become more expensive. If you’re looking for a smaller, more affordable option, TEAMSable 22P-RM-DS 22″ digital display is a great choice.

This digital display is designed for small businesses, restaurants, trade shows, and other events where space is limited. It’s a fully-functional display that supports high-definition content and includes a number of input options.

The TEAMSable 22P-RM-DS is a great option for businesses and organizations that want to take advantage of digital displays and stay on budget. Its small size and affordable price make it a perfect choice for those who are looking for an alternative to traditional signage.

Powered by Android and with a 10-point capacitive touchscreen, the 22P-RM-DS will help you create an unforgettable experience for customers and visitors.

Get started with our experts today

Smaller is Better

If you’re tight on space, the 22″ screen on the TEAMSable 22P-RM-DS is a perfect size. It’s big enough to make an impact but small enough to fit in small spaces.

Fully Functional

This digital display is fully functional and supports high-definition content. It includes a number of input options, so you can connect it to any device you need.

Affordable Option

A more affordable option than other digital displays on the market. Take advantage of digital signage without breaking the bank.
