The TEAMSable M300 series produces clear, precise, and archive-quality documents.

SKU: M300E/M300S Category:
Product Details
Specifications
Downloads
Overview
TEAMSable M300E / M300S

The TEAMSable M300 series produces clear, precise, and archive-quality documents. It is ideal for requisitions and receipts, including coupons, rebates, and special offers. Featuring trouble-free drop-and-print paper loading, the extraordinarily reliable M300 provides paper "pull" technology for jam-free operation and best-in-class cutter performance

  • 19.6mm/Second
  • M300E: USB / Ethernet
    M300S: Serial / USB
  • Support Two 24V DC Drawers w/Compulsion
  • RAM: 8KB RAM, Bitmap: 8KB,
    Flash: 128KB
  • Auto-Cutter with selectable Full or Partial Cut
  • 80/76/69.5/57.5mm Paper Roll
Configurations
Energy Star Certified
Energy Star Certified
Includes USB, Serial and Cash Drawer Interface
M300E Includes USB, Serial and Cash Drawer Interface
M300S Includes Impact Printer, Serial Interface
Wall-mountable
Wall-mountable
MODEL DESCRIPTION
M300E Impact Printer, Ethernet Interface
M300S Impact Printer, Serial Interface
Packaging
Box Details 11.75"(L) x 8.75"(W) x 10.5"(H)
Weight: 8.5lb
Inside the Box Impact Printer
Paper Roll
USB Cable
Serial Cable
Power Cable
Ribbon
Manual
CD-Rom
HARDWARE
Print Speed 4.7 Lines per Second / 19.6mm per Second
Printing Method Impact
Character Per Line Font A: 33 / 35
Font B: 40 / 42
Character Size Font A: 9 x 9
Font B: 7 x 9
Paper Roll Type-
Width
Maximum Diameter
Auto Paper Cutting Method
80/76/69.5/57.5mm ± 0.5mm
83mm
Auto-Cutter with Selectable Full or Partial Cut
Reliability MTBF 180,000 Hours
HARDWARE
Interface M300E - Cash Drawer + USB + Ethernet
M300S - Serial + USB + Cash Drawer
Paper Roll Size Built in
Buzzer Built in
Cash Drawer Port Support Two 24V DC Drawers w/ Compulsion
Data Buffer RAM: 8KB RAM, Bitmap: 8KB, Flash: 128KB
Paper Supply Drop and Print
Power Supply 100-240V AC, 50/60 Hz Adapter included
Power Usage 1.5A / 36W
Compatibility ESC/POS
Driver Windows, Linux, Android, Java POS, OPOS





Download Drivers



V2.0 Windows Driver (Setup File)

BTP-M300-V2.0-Windows-Driver.zip | 6.1MB

LinuxDrv_EN_V1.0

BTP-M300_LinuxDrv_EN_V1.0.zip | 173kb

POS SDK For Android V2.0.6.5

POS-SDK-For-Android-V2.0.6.5.zip | 6.1MB

Printer Utility V1.66

PrinterUtility-V1.66.zip | 10MB

OPOS Win SV4.16-00

SNBCOPOS_Win-SV4.16-00.zip | 9.2MB

POS SDK For iOS V2.10

1_POS-SDK-For-iOS-V2.10.zip | 6.2MB









Java POS

M300 BYJavaPOS_Windows V2.10.zip | 19.3MB |

Language Pack, Simplified Chinese

M300 Simplified Chinese.zip | 138KB |

Language Pack, Chinese

M300 Traditional Chinese.zip | 629KB |

Feed Button

BTP-M300 Feed Button Program Guide V1.00.pdf | 134KB |

User Manual

BTP-M300 User's Manual V1.0.pdf | 2MB |
