Thermal Printer

Setting the standard for value-class thermal receipt printers, TEAMSable delivers an affordable POS printer that provides all popular connection interfaces, including USB, Serial and Ethernet, with state-of-the-art speed and best-in-class reliability.

SKU: R180II Category:
Product Details
Specifications
Downloads
Overview
TEAMSable R180II

Setting the standard for value-class thermal receipt printers, TEAMSable delivers an affordable POS printer that provides all popular connection interfaces, including USB, Serial and Ethernet, with state-of-the-art speed and best-in-class reliability.

  • 230mm/Second
  • Serial / USB / Ethernet
  • Supports Two 24V DC Drawers
    w/Compulsion
  • RAM: 64GB, Bitmap: 128KB,
    Flash: 512KB
  • 203x180 Resolution
  • 80x80mm Paper Roll
Configurations
Energy star certified & Liquid spill guard
Energy star certified & Liquid spill guard
Includes USB Serial and Ethernet
Includes USB, Serial and Ethernet
Wall-mountable
Wall-mountable
MODEL DESCRIPTION
TSP-R180II Thermal Printer, Ethernet, USB, Serial interfaces
Packaging
Box Details 10.5"(L) x 8.75"(W) x 9.75"(H)
Weight: 5.2lb
Inside the Box Thermal Printer R180II
AC Power Input Cable
Power Adapter
Serial Communication Cable
USB Communication Cable
User’s Quick Reference
Paper Roll
HARDWARE
Print Speed 230mm/Second (63 Lines/ Second)
Paper Cutting Method Auto Cutter, Selectable Full or Partial Cutter
Resolution 180 DPI x 180 DPI
Character Per Line Font A: 42 (72mm)/ 33 (58mm)
Font B: 56 (72mm)/ 45 (58mm)
Character Size Font A: 12 x 24;
Font B: 9 x 17
Paper Supply Drop and Print
Reliability MTBF 360,000 Hours
Compatibility ESC/POS
HARDWARE
Interface Serial + USB + Ethernet
Paper Roll Size Built in
Buzzer Built in
Cash Drawer Port Support Two 24V DC Drawers w/ Compulsion
Data Buffer RAM: 64KB RAM, Bitmap: 128KB, Flash: 512KB
Power Supply 100-240V AC, 50/60 Hz Adapter included
Power Usage 1.5A / 36W
Driver Windows, Linux, Android, Java POS, OPOS





Download Drivers





Windows V1.15 (Setup File)

BTP-R180II-Windows-V1.15.zip | 6.9MB

Printer Utility V1.66

2_PrinterUtility-V1.66.zip | 10MB

OPOS Win SV4.16-00

1_SNBCOPOS_Win-SV4.16-00.zip | 9.2MB

LinuxDrv_EN_V1.0

0_BTP-R180II_LinuxDrv_EN_V1.0.zip | 226kb

POS SDK For Android V2.0.6.5

1_POS-SDK-For-Android-V2.0.6.5.zip | 6MB

POS SDK For iOS V2.10

1_POS-SDK-For-iOS-V2.10-1.zip | 6.2MB

JavaPOS Win V3.05

JavaPOS_Win V3.05.zip | 14.4MB |













VCOM

VCOM Win 7 - Win 10_2018.zip | 3.8MB |

Language Pack, Simplified Chinese

Chinese_GB2312.zip | 318KB |

Language Pack, Chinese

Chinese_Big_5.zip | 629KB |

Feed Button

BTP-R180II Push Button V1.0.pdf | 249KB |

User Manual

BTP-R180II User's ManualV1.0.pdf | 1.3MB |

User Manual

OPOS_DRIVER_NOTES.pdf | 154KB |

User Manual

Print_Messenger_Operation_Guide.pdf | 255KB |
